STRETCH FABRIC ACOUSTIC WALL AND CEILING PANELLING MANUFACTURER & SUPPLIERS IN INDIA.

Envirotech Systems manufacturer of Stretch Fabric Acoustic Panel System provides best NRC value and aesthetically pleasing look for Wall and Ceiling. Acoustic panel having Stretch fabric finish for controlling the sound reverberation and echo. Envirotech Stretch Fabric Acoustic Panels are high performance acoustical products with an exceptional visual appearance in Fabric texture. Fabric Acoustical panels comes in a variety of configurations to meet all interior and acoustical requirements, provide full absorption through Insulation Material. NRC System can be utilised as per choice of the Architect or acoustic consultants’ requirement. 50mm thick Rockwool 48kg/m3 density along with Wood Fiber Board of 400kg/m3 Density to increase sound absorption value as per Acoustic Consultant’s design.

Stretch Fabric Acoustical wall panelling system consisting of Acoustically Transparent fabric with high-performance core material for softness and acoustically transparent Jute Fabric as face covering as per selected colour, Fabric stretched by using combination of Strut and Tracks, along with Wood fiber Panel size of 600x1200x15mm, 15mm Wood Fiber base over 50mm high GI Channel, the system is back lined with the acoustical infill Polyester Fiber Wool on front covering for enhancing Acoustic Performance and cushioning over Wood Fiber Panel and cavity area infilled with 50 mm thick Rock wool 48kg/m3 density for better absorption value. The item includes strut system of thickness 0.55mm, length 3600mm, knurled web 40mm, depth 10mm and equal flanges 15mm is fastened to primary wall panelling system behind horizontally at 600mm centres. 15mm Wood Fiber Panel base is then installed on the strut along the marking lines with metal fasteners at 300mm centres. as per Architectural & Acoustical Design & Instructions & Complete in all aspects.

Technical Specification

  • Stretch Fabric Acoustical wall panelling system consisting of Acoustically Transparent fabric with high-performance core material for softness and acoustically transparent Jute Fabric as face covering as per selected colour, Fabric stretched by using combination of Strut and Tracks, along with Wood fiber Panel size of 600x1200x15mm, 15mm Wood Fiber base over 50mm high GI Channel, the system is back lined with the acoustical infill Polyester Fiber Wool on front covering for enhancing Acoustic Performance and cushioning over Wood Fiber Panel and cavity area infilled with 50 mm thick Rock wool 48kg/m3 density for better absorption value. The item includes strut system of thickness 0.55mm, length 3600mm, knurled web 40mm, depth 10mm and equal flanges 15mm is fastened to primary wall panelling system behind horizontally at 600mm centres. 15mm Wood Fiber Panel base is then installed on the strut along the marking lines with metal fasteners at 300mm centres. as per Architectural & Acoustical Design & Instructions & Complete in all aspects.
  • Thickness of the Panelling 78mm or as per choice.
  • Finish: Variety of shades. Having Multiple colour option available.

Technical Parameter

  • Core- Wood Fiber and Rockwool
  • Edge - Square
  • Density- 400kg/m3
  • NRC Value-0.90
  • RH- 85
  • Insulation Material Fire Rating- Class 1 & P
  • Light Reflection- Colour Dependent

Applications

Auditoriums, Conference Rooms, Cinema Halls, Theatres, Music Hall, Stadium, Lecture Hall, Library, Multi-function Hall, Hotels, Museums, Meeting Rooms, Business office and other public places.
